ToLEDo NEOS T8 CCG L1200 1800LM 865 30K RL
ToLEDo NEOS T8 CCG and AC
Product features
- Energy efficient and affordable LED T8 solution to replace conventional fluorescent T8 lamps
- Omni-directional uniform light distribution thanks to glass tube construction design, same as traditional fluorescent T8 tubes
- Lumen output - 1800lm
- High lumen efficacy - 135 lm/W
- Switching cycles - 200,000X
- Average rated life 30,000 hours
- Lamp length - 1200mm
- Wide beam angle
- Suitable for general illumination in offices, supermarkets, department stores, parking lots
- Suitable for operation with electromagnetic gears/CCG and direct mains operation (220-240V)
- 3-Year warranty
Product overview
| Product overview | |
|---|---|
| Product name | ToLEDo NEOS T8 CCG L1200 1800LM 865 30K RL |
| Technology | LED |
| Lamp shape | Tube, double-ended |
| Cap/Base | G13 |
| Lamp finish | Frosted/Coated |
| General application | Education, Logistics & Industry, Office, Residential & Consumer |
| ETIM Class | EC001959 |
| E-number FI | 4941338 |
| Useful luminous flux (Φuse) | 1800 |
| Correlated colour temperature (k) | 6500 |
| Light colour | Daylight |
| CRI (Ra) | 80 |
| Colour Variation Initial (SDCM) | SDCM6 |
| Beam Angle (°) | 170 |
| Photobiological Risk Group | RG0 |
| Power consumption (W) | 13.3 |
| Wattage (W) | 13.3 |
| Dimmable | No |
| IP rating | IP20 |
| Product EAN number | 5410288302331 |
| Warranty | 3 years |
Product Data
| General data | |
|---|---|
| Product name | ToLEDo NEOS T8 CCG L1200 1800LM 865 30K RL |
| Technology | LED |
| Lamp shape | Tube, double-ended |
| Cap/Base | G13 |
| Lamp finish | Frosted/Coated |
| General application | Education, Logistics & Industry, Office, Residential & Consumer |
| Operating temperature range (°C) | -20°C...+45°C |
| ETIM Class | EC001959 |
| E-number FI | 4941338 |
| Warranty | 3 years |
| Optical data | |
|---|---|
| Useful luminous flux (Φuse) | 1800 |
| Correlated colour temperature (k) | 6500 |
| Light colour | Daylight |
| CRI (Ra) | 80 |
| Colour Variation Initial (SDCM) | SDCM6 |
| Beam Angle (°) | 170 |
| Photobiological Risk Group | RG0 |
| Electrical data | |
|---|---|
| Power consumption (W) | 13.3 |
| Wattage (W) | 13.3 |
| Primary Supply/Product voltage - min (V) | 220 |
| Primary Supply/Product voltage - max (V) | 240 |
| Lamp power factor | 0.5 |
| Control gear required | No |
| Dimmable | No |
| Inrush Current (A) | 13.7 |
| Inrush Duration (µs) | 27 |
| Lamp Energy Label (class) | D |
| Nominal Frequency (Hz) | 50/60Hz |
| Lifetime data | |
|---|---|
| Lifespan L70 B50 | 30000 |
| Physical data | |
|---|---|
| IP rating | IP20 |
| Nominal Product Length (mm) | 1198 |
| Nominal Product Diameter (mm) | 28 |
| Weight (kg) | 0.25 |
| Packaging | |
|---|---|
| Product EAN number | 5410288302331 |
| Packaging single length / height (cm) | 126.0 |
| Packaging single width (cm) | 2.8 |
| Packaging single depth (cm) | 2.8 |
| DUN14 (inner) | 15410288302338 |
| Units per outer package | 10 |
| Packaging outer length / height (cm) | 129.0 |
| Packaging outer width (cm) | 15.5 |
| Packaging outer depth (cm) | 8.5 |
| Safety data | |
|---|---|
| Optimal operating condition (°C) | -20-45 |
| Breakage cleaning instructions | Not applicable |
| Special purpose lamp | No |
| Suitable for household illumination | Yes |
| Safety message | Not Suitable for totally enclosed fixtures |
