Flex Pro IP20 9700lm 940
Flex Pro High Output
Product features
- 5 metre IP20 LED reel with pre-attached 3M adhesive type; equipped with 400 LEDs; 9700lm per 5m (1940lm per 1m); 24V; 4000K; CRI90; R9>50; SDCM≤3;Compatible with emergency packs: 0046600, 0046601
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/Ballast.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/CE.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/IP20.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Icons/EN/Class_III.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/IK00.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Icons/EN/Indoor_Use.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Icons/EN/DIM.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/UKCA black fill.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/WEEE-Dustbin.png?maxheight=36)
![](https://cloud.sylvania-lighting.online/assets/Hybris_V2/Icons/EN/650.png?maxheight=36)
Product overview
Product overview | |
---|---|
Product name | Flex Pro IP20 9700lm 940 |
Technology | LED |
Mount | Other |
General application | Hospitality |
ETIM Class | EC002706 |
E-number FI | 4278338 |
Useful luminous flux (Φuse) | 9700 |
Fixture luminous flux (lm) | 9700 |
Luminaire efficacy (lm/W) | 133 |
Correlated colour temperature (k) | 4000 |
Light colour | Neutral White |
CRI (Ra) | 90 |
Colour Variation Initial (SDCM) | SDCM3 |
Beam Angle (°) | 120 |
Photobiological Risk Group | RG1 |
Power consumption (W) | 72 |
Total power consumption (W) | 72 |
Electrical protection | Class III |
Dimmable | Yes |
Dimming method | Other |
IP rating | IP20 |
IK rating | IK00 |
Product EAN number | 5410288681856 |
Warranty | 5 years |
Product Data
General data | |
---|---|
Product name | Flex Pro IP20 9700lm 940 |
Technology | LED |
Mount | Other |
General application | Hospitality |
Operating temperature range (°C) | -20°C...+40°C |
Performance ambient temperature Tq (°C) | 25 |
ETIM Class | EC002706 |
E-number FI | 4278338 |
Warranty | 5 years |
Optical data | |
---|---|
Useful luminous flux (Φuse) | 9700 |
Fixture luminous flux (lm) | 9700 |
Luminaire efficacy (lm/W) | 133 |
Correlated colour temperature (k) | 4000 |
Light colour | Neutral White |
CRI (Ra) | 90 |
Colour Variation Initial (SDCM) | SDCM3 |
Beam Angle (°) | 120 |
Photobiological Risk Group | RG1 |
Electrical data | |
---|---|
Power consumption (W) | 72 |
Total power consumption (W) | 72 |
Primary Supply/Product voltage - min (V) | 24 |
Primary Supply/Product voltage - max (V) | 24 |
Electrical protection | Class III |
Control gear required | Yes |
Dimmable | Yes |
Dimming method | Other |
Drive current (mA) | 3000 |
Glow Wire Test (°C) | 650 |
Lamp Energy Label (class) | E |
Nominal Frequency (Hz) | N/A |
Lifetime data | |
---|---|
Lifespan L70 B50 | 54000 |
Lifespan L70 B10 | 54000 |
Lifespan L80 B10 | 50000 |
Lifespan L90 B10 | 44000 |
Physical data | |
---|---|
IP rating | IP20 |
IK rating | IK00 |
Nominal Product Length (mm) | 5000 |
Nominal Product Width (mm) | 10 |
Nominal Product Height (mm) | 1.2 |
Weight (kg) | 0.1 |
Packaging | |
---|---|
Product EAN number | 5410288681856 |
Packaging single length / height (cm) | 23.5 |
Packaging single width (cm) | 22.5 |
Packaging single depth (cm) | 3.0 |
DUN14 (outer) | 15410288681853 |
Units per outer package | 20 |
Packaging outer length / height (cm) | 49.0 |
Packaging outer width (cm) | 35.0 |
Packaging outer depth (cm) | 24.0 |
Safety data | |
---|---|
Optimal operating condition (°C) | -20-40 |
